SGI030

Repeatability：0.05μm

Working distance：30mm

Linearity：±0.05%F.S.

Sampling frequency：1k-88kHz

Small spot：Ø60μm

Temperature characteristic：0.01%F.S./℃

Favorites Saved to favorites

Product Specifications


Model	SGI030
Reference distance (RF)	30 mm
Measuring range	±5 mm
Light source wavelength	655 nm
Laser class	Class II
Spot size (Reference distance)	Φ60 μm
Repeatability	0.05 μm
Linearity	±0.05% F.S.
Temperature characteristics	0.01% F.S./℃
Sampling refresh rate	1000/2000/5000/10000/20000/50000/88000 kHz
Communication port	1 100Base-TX/1000Base-T Ethernet interface，1 RS485
Analog output	1-channel analog outputs，supports analog voltage and analog current switching
IO input	2 channels timing，zeroing and single-ended encoder function multiplexing
IO output	4 channel，determines status of output
Operating temperature	-10~50 ℃
Storage temperature	-20～70 ℃
Working humidity	35%-85% no condensation
ESD protection	Contact discharge 4kV，air discharge 8kV， conforms with IEC61000-4-2 standard
EFT protection	Power port 2kV/5 or 100kHz，signal port 1kV/5 or 100kHz， conforms with IEC61000-4-4
Bumps	50Gs/3ms on each axis， conforms with IEC 68-2-27 Ea
Vibrations	10Gs (10-500Hz)， conforms with IEC 68-2-6 Fc
IP level	IP67， conforms with IEC 60529 standard
Dimensions	907541 mm
Weight (including cable)	324 g
