SG3035

Repeatability: 0.05μm

Working distance: 30mm

Measurement range: ±5mm

Linearity: ±0.05% F.S.

Sampling frequency: 1/2/5/10/20/50/88kHz (7 selectable levels)

Spot diameter: Large spot: Φ60μm; Wide spot: 60*400μm

Favorites Saved to favorites

CE, FCC compliant

Product Specifications


Model	SG3035
Reference distance (RF)	30 mm
Measuring range	±5 mm
Light source wavelength	655 nm
Laser class	Class II
Spot size (Reference distance)	60*400 μm
Repeatability	0.05 μm
Linearity	±0.05% F.S.
Temperature characteristics	0.01% F.S./℃
Sampling refresh rate	1/2/5/10/20/50/88 kHz
Communication port	1 100Base-TX/1000Base-T Ethernet interface，1 RS232
Analog output	4-channel analog outputs， supports analog voltage and analog current switching
IO input	14 channels，supports timing， zeroing， reset， laser control， recipe switching and other functions
IO output	16 channel， determines status of output
Operating temperature	0～50 ℃
Storage temperature	-20～70 ℃
Working humidity	35%-85% no condensation
ESD protection	Contact discharge 4kV，air discharge 8kV， conforms with IEC61000-4-2 standard
EFT protection	Power port 2kV/5 or 100kHz，signal port 1kV/5 or 100kHz， conforms with IEC61000-4-4
Bumps	50Gs/3ms on each axis， conforms with IEC 68-2-27 Ea
Vibrations	10Gs (10-500Hz)， conforms with IEC 68-2-6 Fc
IP level	IP67， conforms with IEC 60529 standard
Dimensions	907538 mm
Weight (including cable)	324 g
