HP300 Plus
Tissue Processor

Self-test — Automatically check key operation parameters before the process starts, minimizing the possibility of malfunction from the beginning.

Dual air pump system — Two air pumps can work individually or jointly to ensure instrument accountability.

Dual temperature sensors — Shift control algorithm spontaneously to provide excellent temperature control.

Component monitoring — Real-time monitoring of components and parameter settings. Together with intelligent analysis and precaution, further offers great overall performance.

Alcohol concentration sensor — On-board high precision sensor detects alcohol concentration to prevent incorrect replenishment.

Ceramic rotary valve — Heat-resistant ceramic valve significantly reduces blockage caused by wax attachment and thus promotes the stability and accuracy of liquid delivery.

Ultrasonic sensors — Ultrasonic liquid level sensors unaffected by wax build ups are able to provide correct liquid level information consistently.

Use only the correct reagent — Identification module built in every reagent bottle enables auto reagent information extraction and position detection to streamline reagent management.

Multi-dimensional reagent management — Multi-dimensional monitoring of reagent usage, reagent replenishment record can be generated and exported for lab statisctics.
Consumption can be recorded in cassettes, cycles and days.

Electric lock — Electric lock can be triggered on touch screen effortlessly and offers better sealing.

Cleaning xylene pre-heating — Heating module under cleaning xylene bottles can heat to 40 - 55℃, further improving cleaning performance and efficiency.

Remote fill & drain — Reagent ports exclusively for easy and automatic remote fill & drain.

Wax purification — Innovative wax purification feature removes solvent residue in wax, extending its service life.
